WAP to generate the target code by using labelling algorithm.
/*
2) WAP to generate the target code by using labelling algorithm.
Input: Labelled tree
Output: Target code
*/
#include<stdio.h>
#include<stdlib.h>
typedef struct holder
{
char name[5];
int label;
struct holder * left,*right;
}node;
node * root=NULL, *temp;
node * getnode()
{
return((node*)malloc(sizeof(node)));
}
int rstack[3]={0,1,2},tstack[3]={0,1,2},rtop=0,ttop=0;
char * mapop(char op[5])
{
if(strcmp("+",op)==0)
return("ADD");
if(strcmp("-",op)==0)
return("SUB");
if(strcmp("*",op)==0)
return("MUL");
if(strcmp("/",op)==0)
return("DIV");
if(strcmp("=",op)==0)
return("MOV");
return("Error");
}
node * create()
{
node * temp;
char name[5];
temp=getnode();
printf("\n\tEnter Node : ");
scanf("%s",temp->name);
printf("\n\tIs there left node present for %s (y / n): ",temp->name);
scanf("%s",name);
if(strcmp(name,"y")==0)
temp->left=create();
else
temp->left=NULL;
printf("\n\tIs there right node present for %s (y / n): ",temp->name);
scanf("%s",name);
if(strcmp(name,"y")==0)
temp->right=create();
else
temp->right=NULL;
return(temp);
}
int label(node * temp)
{
node * temp1;
if(temp->left!=NULL || temp->right!=NULL)
{
label(temp->left);
label(temp->right);
temp1=temp->left;
if(temp1->left==NULL && temp1->right==NULL) //left leaf node
temp1->label=1;
else if(temp1->left->label == temp1->right->label)
temp1->label=temp1->left->label+1;
else
if(temp1->left->label > temp1->right->label)
temp1->label=temp1->left->label;
else
temp1->label=temp1->right->label;
temp1=temp->right;
if(temp1->left==NULL && temp1->right==NULL) // rt leaf
temp1->label=0;
else if(temp1->left->label == temp1->right->label)
temp1->label=temp1->left->label+1;
else
if(temp1->left->label > temp1->right->label)
temp1->label=temp1->left->label;
else
temp1->label=temp1->right->label;
}
}
void swap()
{
int temp=rstack[rtop];
rstack[rtop]=rstack[rtop+1];
rstack[rtop+1]=temp;
}
void codegen(node * temp)
{
int i;
if(temp==NULL)
return;
if(temp->left==NULL && temp->right==NULL && temp->label==1) //ie left leaf node
printf("\n\tMOV %s , R%d\t#L",temp->name,rstack[rtop++]);
else if(temp->right->label==0) // rt leaf
{
codegen(temp->left);
printf("\n\t%s %s , R%d\t#R",mapop(temp->name),temp->right->name,rstack[rtop-1]);
}
else if(temp->left->label < temp->right->label && temp->left->label<3)
{
int R;
swap();
codegen(temp->right);
R=rstack[rtop-1];
//poping
for(i=rtop-1;i<3;i++)
rstack[i]=rstack[i+1];
rtop--;
codegen(temp->left);
printf("\n\t%s R%d , R%d\t#1",mapop(temp->name),R,rstack[rtop-1]);
//pushing
rstack[rtop++]=R;
swap();
}
else if(temp->left->label > temp->right->label && temp->right->label<3)
{
int R;
codegen(temp->left);
R=rstack[rtop-1];
//poping
for(i=rtop-1;i<3;i++)
rstack[i]=rstack[i+1];
rtop--;
codegen(temp->right);
printf("\n\t%s R%d , R%d\t#2",mapop(temp->name),R,rstack[rtop-1]);
//pushing
rstack[rtop++]=R;
}
else
{
int T;
codegen(temp->right);
T=tstack[ttop--];
printf("\n\tMOV R%d , T%d",rstack[rtop-1],T);
codegen(temp->left);
ttop++;
printf("\n\t%s T%d , R%d",mapop(temp->name),T,rstack[rtop-1]);
}
}
void print(node * temp)
{
if(temp!=NULL)
{
print(temp->left);
print(temp->right);
printf("\n\t %s \t %d",temp->name,temp->label);
}
}
int main()
{
int i,j,k,no;
printf("\n\tEnter syntax tree : ");
root=create();
label(root);
if(root->left->label == root->right->label)
root->label=root->left->label+1;
else if(root->left->label > root->right->label)
root->label=root->left->label;
else
root->label=root->right->label;
codegen(root);
print(root);
}
read more
2) WAP to generate the target code by using labelling algorithm.
Input: Labelled tree
Output: Target code
*/
#include<stdio.h>
#include<stdlib.h>
typedef struct holder
{
char name[5];
int label;
struct holder * left,*right;
}node;
node * root=NULL, *temp;
node * getnode()
{
return((node*)malloc(sizeof(node)));
}
int rstack[3]={0,1,2},tstack[3]={0,1,2},rtop=0,ttop=0;
char * mapop(char op[5])
{
if(strcmp("+",op)==0)
return("ADD");
if(strcmp("-",op)==0)
return("SUB");
if(strcmp("*",op)==0)
return("MUL");
if(strcmp("/",op)==0)
return("DIV");
if(strcmp("=",op)==0)
return("MOV");
return("Error");
}
node * create()
{
node * temp;
char name[5];
temp=getnode();
printf("\n\tEnter Node : ");
scanf("%s",temp->name);
printf("\n\tIs there left node present for %s (y / n): ",temp->name);
scanf("%s",name);
if(strcmp(name,"y")==0)
temp->left=create();
else
temp->left=NULL;
printf("\n\tIs there right node present for %s (y / n): ",temp->name);
scanf("%s",name);
if(strcmp(name,"y")==0)
temp->right=create();
else
temp->right=NULL;
return(temp);
}
int label(node * temp)
{
node * temp1;
if(temp->left!=NULL || temp->right!=NULL)
{
label(temp->left);
label(temp->right);
temp1=temp->left;
if(temp1->left==NULL && temp1->right==NULL) //left leaf node
temp1->label=1;
else if(temp1->left->label == temp1->right->label)
temp1->label=temp1->left->label+1;
else
if(temp1->left->label > temp1->right->label)
temp1->label=temp1->left->label;
else
temp1->label=temp1->right->label;
temp1=temp->right;
if(temp1->left==NULL && temp1->right==NULL) // rt leaf
temp1->label=0;
else if(temp1->left->label == temp1->right->label)
temp1->label=temp1->left->label+1;
else
if(temp1->left->label > temp1->right->label)
temp1->label=temp1->left->label;
else
temp1->label=temp1->right->label;
}
}
void swap()
{
int temp=rstack[rtop];
rstack[rtop]=rstack[rtop+1];
rstack[rtop+1]=temp;
}
void codegen(node * temp)
{
int i;
if(temp==NULL)
return;
if(temp->left==NULL && temp->right==NULL && temp->label==1) //ie left leaf node
printf("\n\tMOV %s , R%d\t#L",temp->name,rstack[rtop++]);
else if(temp->right->label==0) // rt leaf
{
codegen(temp->left);
printf("\n\t%s %s , R%d\t#R",mapop(temp->name),temp->right->name,rstack[rtop-1]);
}
else if(temp->left->label < temp->right->label && temp->left->label<3)
{
int R;
swap();
codegen(temp->right);
R=rstack[rtop-1];
//poping
for(i=rtop-1;i<3;i++)
rstack[i]=rstack[i+1];
rtop--;
codegen(temp->left);
printf("\n\t%s R%d , R%d\t#1",mapop(temp->name),R,rstack[rtop-1]);
//pushing
rstack[rtop++]=R;
swap();
}
else if(temp->left->label > temp->right->label && temp->right->label<3)
{
int R;
codegen(temp->left);
R=rstack[rtop-1];
//poping
for(i=rtop-1;i<3;i++)
rstack[i]=rstack[i+1];
rtop--;
codegen(temp->right);
printf("\n\t%s R%d , R%d\t#2",mapop(temp->name),R,rstack[rtop-1]);
//pushing
rstack[rtop++]=R;
}
else
{
int T;
codegen(temp->right);
T=tstack[ttop--];
printf("\n\tMOV R%d , T%d",rstack[rtop-1],T);
codegen(temp->left);
ttop++;
printf("\n\t%s T%d , R%d",mapop(temp->name),T,rstack[rtop-1]);
}
}
void print(node * temp)
{
if(temp!=NULL)
{
print(temp->left);
print(temp->right);
printf("\n\t %s \t %d",temp->name,temp->label);
}
}
int main()
{
int i,j,k,no;
printf("\n\tEnter syntax tree : ");
root=create();
label(root);
if(root->left->label == root->right->label)
root->label=root->left->label+1;
else if(root->left->label > root->right->label)
root->label=root->left->label;
else
root->label=root->right->label;
codegen(root);
print(root);
}
WAP to label the tree for code generation
/*
1) WAP to label the tree for code generation.
Input: Syntax Tree
Output: Labelled syntax tree [use any tree traversal method]
*/
#include<stdio.h>
#include<stdlib.h>
typedef struct holder
{
char name[5];
int label;
struct holder * left,*right;
}node;
node * root=NULL, *temp;
node * getnode()
{
return((node*)malloc(sizeof(node)));
}
node * create()
{
node * temp;
char ch[5];
temp=getnode();
printf("\n\tEnter Node : ");
scanf("%s",temp->name);
printf("\n\tIs there left node present for %s (y / n): ",temp->name);
scanf("%s",ch);
if(strcmp(ch,"y")==0)
temp->left=create();
else
temp->left=NULL;
printf("\n\tIs there right node present for %s (y / n): ",temp->name);
scanf("%s",ch);
if(strcmp(ch,"y")==0)
temp->right=create();
else
temp->right=NULL;
return(temp);
}
void label(node * temp)
{
node * temp1;
if(temp->left!=NULL || temp->right!=NULL)
{
label(temp->left);
label(temp->right);
temp1=temp->left;
if(temp1->left==NULL && temp1->right==NULL) //left leaf node
temp1->label=1;
temp1=temp->right;
if(temp1->left==NULL && temp1->right==NULL) // rt leaf
temp1->label=0;
if(temp->left->label == temp->right->label)
temp->label=temp->left->label+1;
else
if(temp->left->label > temp->right->label)
temp->label=temp->left->label;
else
temp->label=temp->right->label;
}
}
void print(node * temp)
{
if(temp!=NULL)
{
print(temp->left);
print(temp->right);
printf("\n\t %s \t %d",temp->name,temp->label);
}
}
int main()
{
int i,j,k,no;
printf("\n\tEnter syntax tree : ");
root=create();
label(root);
if(root->left->label == root->right->label)
root->label=root->left->label+1;
else if(root->left->label > root->right->label)
root->label=root->left->label;
else
root->label=root->right->label;
print(root);
}
read more
1) WAP to label the tree for code generation.
Input: Syntax Tree
Output: Labelled syntax tree [use any tree traversal method]
*/
#include<stdio.h>
#include<stdlib.h>
typedef struct holder
{
char name[5];
int label;
struct holder * left,*right;
}node;
node * root=NULL, *temp;
node * getnode()
{
return((node*)malloc(sizeof(node)));
}
node * create()
{
node * temp;
char ch[5];
temp=getnode();
printf("\n\tEnter Node : ");
scanf("%s",temp->name);
printf("\n\tIs there left node present for %s (y / n): ",temp->name);
scanf("%s",ch);
if(strcmp(ch,"y")==0)
temp->left=create();
else
temp->left=NULL;
printf("\n\tIs there right node present for %s (y / n): ",temp->name);
scanf("%s",ch);
if(strcmp(ch,"y")==0)
temp->right=create();
else
temp->right=NULL;
return(temp);
}
void label(node * temp)
{
node * temp1;
if(temp->left!=NULL || temp->right!=NULL)
{
label(temp->left);
label(temp->right);
temp1=temp->left;
if(temp1->left==NULL && temp1->right==NULL) //left leaf node
temp1->label=1;
temp1=temp->right;
if(temp1->left==NULL && temp1->right==NULL) // rt leaf
temp1->label=0;
if(temp->left->label == temp->right->label)
temp->label=temp->left->label+1;
else
if(temp->left->label > temp->right->label)
temp->label=temp->left->label;
else
temp->label=temp->right->label;
}
}
void print(node * temp)
{
if(temp!=NULL)
{
print(temp->left);
print(temp->right);
printf("\n\t %s \t %d",temp->name,temp->label);
}
}
int main()
{
int i,j,k,no;
printf("\n\tEnter syntax tree : ");
root=create();
label(root);
if(root->left->label == root->right->label)
root->label=root->left->label+1;
else if(root->left->label > root->right->label)
root->label=root->left->label;
else
root->label=root->right->label;
print(root);
}
code optimization techniques: a)strength reduction b) constant folding
### tac.txt #####
1 sq b - c
2 * 2 c c
3 := c - res
4 + a b no1
5 - res no1 res
6 + 3 5 pi
7 := pi - x
8 / x 2 res1
read more
1 sq b - c
2 * 2 c c
3 := c - res
4 + a b no1
5 - res no1 res
6 + 3 5 pi
7 := pi - x
8 / x 2 res1
##### pr_11a.c ######
/*
10) WAP to implement following code optimization techniques:
a)strength reduction b) constant folding
*/
#include<stdio.h>
struct holder
{
char seqno[3],op[3],arg1[8],arg2[8],result[8];
}tac[50];
int cnt=0,i,j,k;
char hunted[8];
int is_const(char arg[8])
{
for(j=0;j<strlen(arg);j++)
if(!isdigit(arg[j]))
return(0);
return(1);
}
void strength_red()
{
//check * sign and try to replace it by + and sq by *
for(i=0;i<cnt;i++)
{
if(strcmp(tac[i].op,"*")==0)
{
if(atoi(tac[i].arg1)==2 && !(is_const(tac[i].arg2)) )
{
strcpy(tac[i].op,"+");
strcpy(tac[i].arg1,tac[i].arg2);
}
else if(atoi(tac[i].arg2)==2 && !(is_const(tac[i].arg1)))
{
strcpy(tac[i].op,"+");
strcpy(tac[i].arg2,tac[i].arg1);
}
}
if(strcmp(tac[i].op,"/")==0 && atoi(tac[i].arg2)==2)
{
strcpy(tac[i].op,"*");
strcpy(tac[i].arg2,"0.5");
}
if(strcmp(tac[i].op,"sq")==0)
{
strcpy(tac[i].op,"*");
strcpy(tac[i].arg2,tac[i].arg1);
}
}
}
void const_folding()
{
//hunt var1 = const +/-/*// const and then insted of arg1 place result replece const
int val=0;
for(i=0;i<cnt;i++)
{
if(is_const(tac[i].arg1)&&is_const(tac[i].arg2))
{
if(strcmp("+",tac[i].op)==0)
sprintf(tac[i].arg1,"%d",atoi(tac[i].arg1)+atoi(tac[i].arg2));
if(strcmp("-",tac[i].op)==0)
sprintf(tac[i].arg1,"%d",atoi(tac[i].arg1)-atoi(tac[i].arg2));
if(strcmp("*",tac[i].op)==0)
sprintf(tac[i].arg1,"%d",atoi(tac[i].arg1)*atoi(tac[i].arg2));
if(strcmp("/",tac[i].op)==0)
sprintf(tac[i].arg1,"%d",atoi(tac[i].arg1)/atoi(tac[i].arg2));
sprintf(tac[i].arg2,"-");
sprintf(tac[i].op,":=");
}
}
}
int main()
{
FILE * fin =fopen("tac.txt","r");
int i;
while(!feof(fin))
{
fscanf(fin,"%s%s%s%s%s",tac[cnt].seqno,tac[cnt].op,tac[cnt].arg1,tac[cnt].arg2,tac[cnt].result);
cnt++;
}
cnt--;
printf("\n\t\t*** $$ PURE INPUT $$ ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
strength_red();
const_folding();
printf("\n\t\t*** After Process ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
fclose(fin);
}
#### output #####
pr@prashant-HP:~/LEX&YACC/11$ cc pr_11a.c
pr@prashant-HP:~/LEX&YACC/11$ ./a.out
*** $$ PURE INPUT $$ ****
Index OP Arg1 Arg2 Result
1 sq b - c
2 * 2 c c
3 := c - res
4 + a b no1
5 - res no1 res
6 + 3 5 pi
7 := pi - x
8 / x 2 res1
*** After Process ****
Index OP Arg1 Arg2 Result
1 * b b c
2 + c c c
3 := c - res
4 + a b no1
5 - res no1 res
6 := 8 - pi
7 := pi - x
8 * x 0.5 res1pr@prashant-HP:~/LEX&YACC/11$
code optimization techniques: a)dead code elimination b) constant propagation
### tac.txt ###
1 := b - c
2 * b c c
3 + b a res
4 - res no1 res
5 := 322 - no
6 := no - x
7 * x c res1
read more
1 := b - c
2 * b c c
3 + b a res
4 - res no1 res
5 := 322 - no
6 := no - x
7 * x c res1
###### pr_10.c ######
/*
9) WAP to implement following code optimization techniques:
a)dead code elimination b) constant propagation
*/
#include<stdio.h>
struct holder
{
char seqno[3],op[3],arg1[8],arg2[8],result[8];
}tac[50];
int cnt=0,i,j,k,used,isnum;
char hunted[8];
void removeline(int no)
{
for(k=no;k<=cnt;k++)
tac[k]=tac[k+1];
cnt--;
}
void eliminate_dead()
{
//if not used in future remove that line
for(i=0;i<cnt-1;i++)
{
used=0;
strcpy(hunted,tac[i].result);
for(j=i+1;j<cnt;j++)
{
if(strcmp(tac[j].arg1,hunted)==0 || strcmp(tac[j].arg2,hunted)==0)
{
used=1;
break;
}
}
if(!used)
{
printf("\n\t Removing .. %s",tac[i].seqno);
removeline(i);
i--;
}
}
}
void const_propo()
{
//hunt var1 = const and insted of var1 replece const
for(i=0;i<cnt;i++)
{
if(strcmp(tac[i].op,":=")==0 && strcmp(tac[i].arg2,"-")==0)
{
isnum=1;
for(j=0;j<strlen(tac[i].arg1);j++)
if(!isdigit(tac[i].arg1[j]))
isnum=0;
if(isnum)
{
strcpy(hunted,tac[i].result);
for(k=i+1;k<cnt;k++)
{
if(strcmp(tac[k].arg1,hunted)==0)
strcpy(tac[k].arg1,tac[i].arg1);
if(strcmp(tac[k].arg2,hunted)==0)
strcpy(tac[k].arg2,tac[i].arg1);
}
}
}
}
}
int main()
{
FILE * fin =fopen("tac.txt","r");
int i;
while(!feof(fin))
{
fscanf(fin,"%s%s%s%s%s",tac[cnt].seqno,tac[cnt].op,tac[cnt].arg1,tac[cnt].arg2,tac[cnt].result);
cnt++;
}
cnt--;
printf("\n\t\t*** PURE INPUT ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
const_propo();
printf("\n\t\t*** After Process ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
printf("\n\tEnter t0 cont..");
scanf("%d",&i);
eliminate_dead();
printf("\n\t\t*** After Process ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
fclose(fin);
}
### output #####
./a.out
*** PURE INPUT ****
Index OP Arg1 Arg2 Result
1 := b - c
2 * b c c
3 + b a res
4 - res no1 res
5 := 3 - pi
6 := pi - x
7 * x c res1
*** After Process ****
Index OP Arg1 Arg2 Result
1 := b - c
2 * b c c
3 + b a res
5 := 3 - pi
7 * 3 c res1
optimization techniques: a)common sub-expression elimination b)variable propagation
###### tac.txt #######
1 + b a rep
2 * 2 c a
3 := c - res
4 + b a no1
5 - res no1 res
6 + 3 5 temp
7 := temp - x
8 * x c res1
###### pr_9.c ########
/*
8) WAP to implement following code optimization techniques:
a)common sub-expression elimination b)variable propagation
*/
#include<stdio.h>
struct holder
{
char seqno[3],op[3],arg1[8],arg2[8],result[8];
}tac[50];
int cnt=0,i,j,k,used=0;
char hunted[8];
void removeline()
{
for(k=j;k<=cnt;k++)
tac[k]=tac[k+1];
cnt--;
}
void eliminate()
{
//hunt value which having op arg1 arg2 same jst result different
for(i=0;i<cnt;i++)
{
used=0;
for(j=i+1;j<cnt;j++)
{
if(strcmp(tac[j].result,tac[i].result)==0||strcmp(tac[i].arg1,tac[j].result)==0 || strcmp(tac[i].arg2,tac[j].result)==0)
used=1;
if(strcmp(tac[j].op,tac[i].op)==0 && strcmp(tac[j].arg1,tac[i].arg1)==0 && strcmp(tac[j].arg2,tac[i].arg2)==0 && !used)
{
//remove this line and replace result field by original result ie of i th location
strcpy(hunted,tac[j].result);
for(k=j+1;k<cnt;k++)
{
if(strcmp(tac[k].arg1,hunted)==0)
strcpy(tac[k].arg1,tac[i].result);
if(strcmp(tac[k].arg2,hunted)==0)
strcpy(tac[k].arg2,tac[i].result);
}
removeline();
}
}
}
}
void var_propo()
{
//hunt var1 = var2 and insted of var2 replece var1
for(i=0;i<cnt;i++)
{
if(strcmp(tac[i].op,":=")==0 && strcmp(tac[i].arg2,"-")==0)
{
strcpy(hunted,tac[i].result);
for(k=i+1;k<cnt;k++)
{
if(strcmp(tac[k].arg1,hunted)==0)
strcpy(tac[k].arg1,tac[i].arg1);
if(strcmp(tac[k].arg2,hunted)==0)
strcpy(tac[k].arg2,tac[i].arg1);
}
}
}
}
int main()
{
FILE * fin =fopen("tac.txt","r");
int i;
while(!feof(fin))
{
fscanf(fin,"%s%s%s%s%s",tac[cnt].seqno,tac[cnt].op,tac[cnt].arg1,tac[cnt].arg2,tac[cnt].result);
cnt++;
}
cnt--;
printf("\n\t\t*** PURE INPUT ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
eliminate();
var_propo();
printf("\n\t\t*** After Process ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
fclose(fin);
}
read more
1 + b a rep
2 * 2 c a
3 := c - res
4 + b a no1
5 - res no1 res
6 + 3 5 temp
7 := temp - x
8 * x c res1
###### pr_9.c ########
/*
8) WAP to implement following code optimization techniques:
a)common sub-expression elimination b)variable propagation
*/
#include<stdio.h>
struct holder
{
char seqno[3],op[3],arg1[8],arg2[8],result[8];
}tac[50];
int cnt=0,i,j,k,used=0;
char hunted[8];
void removeline()
{
for(k=j;k<=cnt;k++)
tac[k]=tac[k+1];
cnt--;
}
void eliminate()
{
//hunt value which having op arg1 arg2 same jst result different
for(i=0;i<cnt;i++)
{
used=0;
for(j=i+1;j<cnt;j++)
{
if(strcmp(tac[j].result,tac[i].result)==0||strcmp(tac[i].arg1,tac[j].result)==0 || strcmp(tac[i].arg2,tac[j].result)==0)
used=1;
if(strcmp(tac[j].op,tac[i].op)==0 && strcmp(tac[j].arg1,tac[i].arg1)==0 && strcmp(tac[j].arg2,tac[i].arg2)==0 && !used)
{
//remove this line and replace result field by original result ie of i th location
strcpy(hunted,tac[j].result);
for(k=j+1;k<cnt;k++)
{
if(strcmp(tac[k].arg1,hunted)==0)
strcpy(tac[k].arg1,tac[i].result);
if(strcmp(tac[k].arg2,hunted)==0)
strcpy(tac[k].arg2,tac[i].result);
}
removeline();
}
}
}
}
void var_propo()
{
//hunt var1 = var2 and insted of var2 replece var1
for(i=0;i<cnt;i++)
{
if(strcmp(tac[i].op,":=")==0 && strcmp(tac[i].arg2,"-")==0)
{
strcpy(hunted,tac[i].result);
for(k=i+1;k<cnt;k++)
{
if(strcmp(tac[k].arg1,hunted)==0)
strcpy(tac[k].arg1,tac[i].arg1);
if(strcmp(tac[k].arg2,hunted)==0)
strcpy(tac[k].arg2,tac[i].arg1);
}
}
}
}
int main()
{
FILE * fin =fopen("tac.txt","r");
int i;
while(!feof(fin))
{
fscanf(fin,"%s%s%s%s%s",tac[cnt].seqno,tac[cnt].op,tac[cnt].arg1,tac[cnt].arg2,tac[cnt].result);
cnt++;
}
cnt--;
printf("\n\t\t*** PURE INPUT ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
eliminate();
var_propo();
printf("\n\t\t*** After Process ****");
printf("\n\tIndex\tOP\tArg1\tArg2\tResult");
for(i=0;i<cnt;i++)
{
printf("\n\t%s\t%s\t%s\t%s\t%s",tac[i].seqno,tac[i].op,tac[i].arg1,tac[i].arg2,tac[i].result);
}
fclose(fin);
}
##### output #######
*** PURE INPUT ****
Index OP Arg1 Arg2 Result
1 + b a c
2 * 2 c c
3 := c - res
4 + b a no1
5 - res no1 res
6 + 3 5 temp
7 := temp - x
8 * x c res1
*** After Process ****
Index OP Arg1 Arg2 Result
1 + b a c
2 * 2 c c
3 := c - res
5 - c c res
6 + 3 5 temp
7 := temp - x
8 * temp c res1
pr@prashant-HP:~/LEX&YACC/9$
grammar to recognize declarations of variables, assignment statement & if- else statement as per syntax of C and generate equivalent three address code
##### pr.h ########
struct holder
{
char name[8];
char type[6];
}st[30];
read more
struct holder
{
char name[8];
char type[6];
}st[30];
##### pr_8.l ######
%{
#include<stdio.h>
#include "y.tab.h"
#include "pr.h"
char var_type[5];
int var_cnt=0,i;
extern yylval;
%}
type int|float|char
cond1 if
cond2 else
%%
main {return(mn);}
{type} {
strcpy(var_type,yytext);
return(Type);
}
{cond1} {return(IF);}
{cond2} {return(ELSE);}
[a-z]+[a-z0-9]* {
for(i=0;i<var_cnt;i++)
if(strcmp(st[i].name,yytext)==0)
break;
if(i==var_cnt)
{
strcpy(st[var_cnt].name,yytext);
strcpy(st[var_cnt++].type,var_type);
}
yylval=i;
return(var);
}
[0-9]+ {yylval=atoi(yytext);return(num);}
[ \t] {;}
. {return(yytext[0]);}
[\n] {;}
%%
##### pr_8.y #######
/*7) Write an attributed translation grammar to recognize declarations of variables, assignment statement & if- else statement as per syntax of C and generate equivalent three address code for the given input made up of constructs mentioned above using LEX and YACC. Write a code to store the identifiers from the input in a symbol table and also to record other relevant information about the identifiers. Display all records stored in the symbol table.
*/
%{
#include<stdio.h>
#include<stdlib.h>
#include "pr.h"
FILE * yyin;
int total_var=0,temp_cnt=0;
char e2_type[6],e1_type[6],e_type[6];
%}
%token mn var Type num IF ELSE WHILE
%%
edash : prog {printf("\n\t!!!End of programm!!!!\n");}
;
prog : mn '('')''{'mstmt'}' {;}
;
mstmt : stmt mstmt
|
stmt
;
stmt : dstmt';' {/*printf("\n\tValid Declration Statement");*/}
|
exstmt';' {//printf("\n\tValid Expression Statement");
}
|
dstmt {printf("\n\t**** Error--- Line Not Terminated by ';' ");}
|
exstmt {printf("\n\t**** Error--- Line Not Terminated by ';'");}
|
ifelse
|
next';'
;
dstmt : Type varlist
;
varlist : v','varlist
|
v
;
v : var {total_var++;}
|
var'='num { total_var++;
//Target code
printf("\n\t%s:=%d",st[$1].name,$3);
}
;
exstmt : var'='e {
if(strcmp(e1_type,"int")==0)
printf("\n\t%s := %d",st[$1].name,$3);
else
printf("\n\t%s:=T%d",st[$1].name,temp_cnt-1);
}
;
e : e '+' e1 {
//target Code
printf("\n\tT%d:=%s+%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e '-' e1 {
//target Code
printf("\n\tT%d:=%s-%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e1 { strcpy(e_type,e1_type);}
;
e1 : e1 '*' e2 {
//target Code
printf("\n\tT%d:=%s*%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e1 '/' e2 {
//target Code
printf("\n\tT%d:=%s/%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e2 {strcpy(e1_type,e2_type);}
;
e2 : var {strcpy(e2_type,st[$1].type);}
|
num { strcpy(e2_type,"int");}
;
next : var'+''+' {printf("\n\t%s=%s+1 ",st[$1].name,st[$1].name);}
|
var '-''-' {printf("\n\t%s=%s-1",st[$1].name,st[$1].name);}
;
ifelse : IF '(' cnd ')' '{' body1 '}' {printf("\nEnd:");}
|
IF '(' cnd ')' '{' body1 '}' ELSE '{' body2 '}' {;}
;
cnd : var '<' var {printf("\n\tIf %s < %s goto next else goto End_IF:\nNext:",st[$1].name,st[$3].name);}
|
var '<' num {printf(" \n\tIf %s < %d goto next else goto End_IF:\nNext:",st[$1].name,$3);}
|
var '>' var {printf(" \n\tIf %s > %s goto next else goto End_IF:\nNext:",st[$1].name,st[$3].name);}
|
var '>' num {printf(" \n\tIf %s > %d goto next else goto End_IF:\nNext:",st[$1].name,$3);}
|
var '<''=' var {printf(" \n\tIf %s <= %s goto next else goto End_IF:\nNext:",st[$1].name,st[$4].name);}
|
var '<''=' num {printf(" \n\tIf %s <= %d goto next else goto End_IF:\nNext:",st[$1].name,$4);}
|
var '>''=' var {printf(" \n\tIf %s >= %s goto next else goto End_IF:\nNext:",st[$1].name,st[$4].name);}
|
var '>''=' num {printf(" \n\tIf %s >= %d goto next else goto End_IF:\nNext:",st[$1].name,$4);}
|
var '!''=' var {printf(" \n\tIf %s != %s goto next else goto End_IF:\nNext:",st[$1].name,st[$4].name);}
|
var '!''=' num {printf(" \n\tIf %s != %d goto next else goto End_IF:\nNext:",st[$1].name,$4);}
|
var '=''=' var {printf(" \n\tIf %s <= %s goto next else goto End_IF:\nNext:",st[$1].name,st[$4].name);}
|
var '=''=' num {printf(" \n\tIf %s <= %d goto next else goto End_IF:\nNext:",st[$1].name,$4);}
;
body1 : mstmt {printf("\n\tGoto End \nEnd_IF:\n");}
;
body2 : mstmt {printf("\nEnd");}
;
%%
int main()
{
int i;
yyin=fopen("ip.c","r");
printf("\n\t***** SEE 3 ADDR code **** ");
yyparse();
printf("\n\t++++Now you want symbal table right??? Then SEE...++++");
for(i=0;i<total_var;i++)
{
printf("\n\t%s\t%s",st[i].name,st[i].type);
}
return(0);
}
void yyerror(char *c)
{
fprintf(stderr,"%s\n",c);
}
####### ip.c ######
main ( )
{
float a=0,b=4,c=5;
int no1 = 0,no2=0;
a=b+c;
no1=no2-a;
if(a<10)
{
c=b+c;
a++;
}
}
grammar to recognize declarations of variables, assignment statement & “while” statement as per syntax of C and generate equivalent three address code
##### pr.h ######
struct holder
{
char name[8];
char type[6];
}st[30];
####### pr_7.l #######
%{
#include<stdio.h>
#include "y.tab.h"
#include "pr.h"
char var_type[5];
int var_cnt=0,i;
extern yylval;
%}
type int|float|char
%%
main {return(mn);}
{type} {
strcpy(var_type,yytext);
return(Type);
}
while {return(WHILE);}
[a-z]+[a-z0-9]* {
for(i=0;i<var_cnt;i++)
if(strcmp(st[i].name,yytext)==0)
break;
if(i==var_cnt)
{
strcpy(st[var_cnt].name,yytext);
strcpy(st[var_cnt++].type,var_type);
}
yylval=i;
return(var);
}
[0-9]+ {yylval=atoi(yytext);return(num);}
[ \t] {;}
. {return(yytext[0]);}
[\n] {;}
%%
######## pr_7.y ##########
/*
6) Write an attributed translation grammar to recognize declarations of variables, assignment statement & “while” statement as per syntax of C and generate equivalent three address code for the given input made up of constructs mentioned above using LEX and YACC. Write a code to store the identifiers from the input in a symbol table and also to record other relevant information about the identifiers. Display all records stored in the symbol table.
*/
%{
#include<stdio.h>
#include<stdlib.h>
#include "pr.h"
FILE * yyin;
int total_var=0,temp_cnt=0;
char e2_type[6],e1_type[6],e_type[6];
%}
%token mn var Type num WHILE
%%
edash : prog {printf("\n\t!!!End of programm!!!!\n");}
;
prog : mn '('')''{'mstmt'}' {;}
;
mstmt : stmt mstmt
|
stmt
;
stmt : dstmt';' {/*printf("\n\tValid Declration Statement");*/}
|
exstmt';' {//printf("\n\tValid Expression Statement");
}
|
dstmt {printf("\n\t**** Error--- Line Not Terminated by ';' ");}
|
exstmt {printf("\n\t**** Error--- Line Not Terminated by ';'");}
|
whileloop
|
next';'
;
dstmt : Type varlist
;
varlist : v','varlist
|
v
;
v : var {total_var++;}
|
var'='num { total_var++;
//Target code
printf("\n\t%s:=%d",st[$1].name,$3);
}
;
exstmt : var'='e {
if(strcmp(e1_type,"int")==0)
printf("\n\t%s := %d",st[$1].name,$3);
else
printf("\n\t%s:=T%d",st[$1].name,temp_cnt-1);
}
;
e : e '+' e1 {
//target Code
printf("\n\tT%d:=%s+%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e '-' e1 {
//target Code
printf("\n\tT%d:=%s-%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e1 { strcpy(e_type,e1_type);}
;
e1 : e1 '*' e2 {
//target Code
printf("\n\tT%d:=%s*%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e1 '/' e2 {
//target Code
printf("\n\tT%d:=%s/%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e2 {strcpy(e1_type,e2_type);}
;
e2 : var {strcpy(e2_type,st[$1].type);}
|
num { strcpy(e2_type,"int");}
;
next : var'+''+' {printf("\n\t%s=%s+1 ",st[$1].name,st[$1].name);}
|
var '-''-' {printf("\n\t%s=%s-1",st[$1].name,st[$1].name);}
;
whileloop : WHILE '(' cnd ')' '{' body '}' {printf("\nEnd : ");}
;
cnd : var '<' var {printf("\nStart:\n\tIf %s < %s goto next else goto End\nNext:",st[$1].name,st[$3].name);}
|
var '<' num {printf("\nStart:\n\tIf %s < %d goto next else goto End\nNext:",st[$1].name,$3);}
|
var '>' var {printf("\nStart:\n\tIf %s > %s goto next else goto End\nNext:",st[$1].name,st[$3].name);}
|
var '>' num {printf("\nStart:\n\tIf %s > %d goto next else goto End\nNext:",st[$1].name,$3);}
|
var '<''=' var {printf("\nStart:\n\tIf %s <= %s goto next else goto End\nNext:",st[$1].name,st[$4].name);}
|
var '<''=' num {printf("\nStart:\n\tIf %s <= %d goto next else goto End\nNext:",st[$1].name,$4);}
|
var '>''=' var {printf("\nStart:\n\tIf %s >= %s goto next else goto End\nNext:",st[$1].name,st[$4].name);}
|
var '>''=' num {printf("\nStart:\n\tIf %s >= %d goto next else goto End\nNext:",st[$1].name,$4);}
;
body : mstmt {printf("\n\tgoto Start");}
;
%%
int main()
{
int i;
yyin=fopen("ip.c","r");
printf("\n\t***** SEE 3 ADDR code **** ");
yyparse();
printf("\n\t++++Now you want symbal table right??? Then SEE...++++");
for(i=0;i<total_var;i++)
{
printf("\n\t%s\t%s",st[i].name,st[i].type);
}
return(0);
}
void yyerror(char *c)
{
fprintf(stderr,"%s\n",c);
}
read more
struct holder
{
char name[8];
char type[6];
}st[30];
####### pr_7.l #######
%{
#include<stdio.h>
#include "y.tab.h"
#include "pr.h"
char var_type[5];
int var_cnt=0,i;
extern yylval;
%}
type int|float|char
%%
main {return(mn);}
{type} {
strcpy(var_type,yytext);
return(Type);
}
while {return(WHILE);}
[a-z]+[a-z0-9]* {
for(i=0;i<var_cnt;i++)
if(strcmp(st[i].name,yytext)==0)
break;
if(i==var_cnt)
{
strcpy(st[var_cnt].name,yytext);
strcpy(st[var_cnt++].type,var_type);
}
yylval=i;
return(var);
}
[0-9]+ {yylval=atoi(yytext);return(num);}
[ \t] {;}
. {return(yytext[0]);}
[\n] {;}
%%
######## pr_7.y ##########
/*
6) Write an attributed translation grammar to recognize declarations of variables, assignment statement & “while” statement as per syntax of C and generate equivalent three address code for the given input made up of constructs mentioned above using LEX and YACC. Write a code to store the identifiers from the input in a symbol table and also to record other relevant information about the identifiers. Display all records stored in the symbol table.
*/
%{
#include<stdio.h>
#include<stdlib.h>
#include "pr.h"
FILE * yyin;
int total_var=0,temp_cnt=0;
char e2_type[6],e1_type[6],e_type[6];
%}
%token mn var Type num WHILE
%%
edash : prog {printf("\n\t!!!End of programm!!!!\n");}
;
prog : mn '('')''{'mstmt'}' {;}
;
mstmt : stmt mstmt
|
stmt
;
stmt : dstmt';' {/*printf("\n\tValid Declration Statement");*/}
|
exstmt';' {//printf("\n\tValid Expression Statement");
}
|
dstmt {printf("\n\t**** Error--- Line Not Terminated by ';' ");}
|
exstmt {printf("\n\t**** Error--- Line Not Terminated by ';'");}
|
whileloop
|
next';'
;
dstmt : Type varlist
;
varlist : v','varlist
|
v
;
v : var {total_var++;}
|
var'='num { total_var++;
//Target code
printf("\n\t%s:=%d",st[$1].name,$3);
}
;
exstmt : var'='e {
if(strcmp(e1_type,"int")==0)
printf("\n\t%s := %d",st[$1].name,$3);
else
printf("\n\t%s:=T%d",st[$1].name,temp_cnt-1);
}
;
e : e '+' e1 {
//target Code
printf("\n\tT%d:=%s+%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e '-' e1 {
//target Code
printf("\n\tT%d:=%s-%s",temp_cnt,st[$1].name,st[$3].name);
temp_cnt++;
}
|
e1 { strcpy(e_type,e1_type);}
;
e1 : e1 '*' e2 {
//target Code
printf("\n\tT%d:=%s*%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e1 '/' e2 {
//target Code
printf("\n\tT%d:=%s/%s",temp_cnt++,st[$1].name,st[$3].name);
}
|
e2 {strcpy(e1_type,e2_type);}
;
e2 : var {strcpy(e2_type,st[$1].type);}
|
num { strcpy(e2_type,"int");}
;
next : var'+''+' {printf("\n\t%s=%s+1 ",st[$1].name,st[$1].name);}
|
var '-''-' {printf("\n\t%s=%s-1",st[$1].name,st[$1].name);}
;
whileloop : WHILE '(' cnd ')' '{' body '}' {printf("\nEnd : ");}
;
cnd : var '<' var {printf("\nStart:\n\tIf %s < %s goto next else goto End\nNext:",st[$1].name,st[$3].name);}
|
var '<' num {printf("\nStart:\n\tIf %s < %d goto next else goto End\nNext:",st[$1].name,$3);}
|
var '>' var {printf("\nStart:\n\tIf %s > %s goto next else goto End\nNext:",st[$1].name,st[$3].name);}
|
var '>' num {printf("\nStart:\n\tIf %s > %d goto next else goto End\nNext:",st[$1].name,$3);}
|
var '<''=' var {printf("\nStart:\n\tIf %s <= %s goto next else goto End\nNext:",st[$1].name,st[$4].name);}
|
var '<''=' num {printf("\nStart:\n\tIf %s <= %d goto next else goto End\nNext:",st[$1].name,$4);}
|
var '>''=' var {printf("\nStart:\n\tIf %s >= %s goto next else goto End\nNext:",st[$1].name,st[$4].name);}
|
var '>''=' num {printf("\nStart:\n\tIf %s >= %d goto next else goto End\nNext:",st[$1].name,$4);}
;
body : mstmt {printf("\n\tgoto Start");}
;
%%
int main()
{
int i;
yyin=fopen("ip.c","r");
printf("\n\t***** SEE 3 ADDR code **** ");
yyparse();
printf("\n\t++++Now you want symbal table right??? Then SEE...++++");
for(i=0;i<total_var;i++)
{
printf("\n\t%s\t%s",st[i].name,st[i].type);
}
return(0);
}
void yyerror(char *c)
{
fprintf(stderr,"%s\n",c);
}
####### ip.c ########
main ( )
{
float a=0,b=4,c=5;
int no1 = 0,no2=0;
a=b+c;
no1=no2-a;
while(a<10)
{
c=b+c;
a++;
}
}
Subscribe to:
Posts (Atom)
